ZM5202AE-CME3R 868 MHz Z-Wave Wireless Transceiver Module
- Delivery nationwide via The Courier Guy — R150 flat, free over R2,000
- Free collection from our Milnerton (Cape Town) warehouse
- Secure checkout — PayFast card payment or EFT
- Questions? WhatsApp us on +27 65 900 8570
Description
The ZM5202AE-CME3R is a fully integrated 868 MHz Z-Wave Sub-GHz wireless transceiver module based on the SD3502 SoC. Featuring an embedded microcontroller, built-in memory, and integrated RF matching, it enables robust short-range wireless communication. It is well suited for makers, students, and engineers prototyping connected home automation and IoT projects.
Integrated Z-Wave SoC architecture
The module combines an SD3502 Z-Wave SoC, embedded microcontroller, crystal oscillator, and passive RF matching components into a single package. With 128 KB of flash memory and 16 KB of SRAM, it is built for single-microcontroller standalone applications.
RF performance and frequency agility
Operating at 868 MHz with data rates up to 100 kbps, the transceiver features a receiver sensitivity of -103 dBm and a transmit power of +4 dBm. Hardware-assisted channel switching provides interference avoidance for dependable wireless transmission.
Interfaces and power efficiency
The module supports SPI, UART, USB, GPIO, and module-dependent PWM interfaces over an operating voltage of 2.3 V to 3.6 V. Designed with very low sleep current, it is optimised for energy efficiency in battery-powered devices.
Typical applications
This surface-mount transceiver is designed for smart home controllers, smart lighting, security systems, and wireless door locks. It is also suitable for home automation sensors and energy management IoT products.
Downloads
Specifications
| Device | IC |
| Device Type | Sub-GHz Wireless Transceiver Module |
| Protocol | Z-Wave |
| Frequency | 868 MHz |
| Data Rate | Up to 100 kbps |
| Receiver Sensitivity | -103 dBm |
| Transmit Power | +4 dBm |
| Supply Voltage | 2.3 V to 3.6 V |
| Receive Current | 32 mA typical |
| Transmit Current | 41 mA typical |
| Flash Memory | 128 KB |
| SRAM | 16 KB |
| Interfaces | SPI, UART, USB, GPIO, PWM |
| Mounting Type | Surface Mount (SMD) |
| Module Dimensions | 13.6 mm × 12.5 mm × 1.9 mm |
| Operating Range | -10°C to +85°C |
