45W DC-DC Converter 9V@5A

The 45W DC-DC Converter steps down a 16V to 36V DC input into a stable 9V DC output at up to 5A. Housed in a rugged casing, it is ideal for powering robotics systems, hobby projects, and vehicle electronics from higher-voltage supplies.

Wide voltage input range

The module accepts any direct current input between 16V and 36V DC and steps it down to a regulated 9V DC output at up to 5A. This makes it well-suited for powering robotic platforms and embedded electronics from multi-cell battery systems.

High efficiency power conversion

Delivering up to 96% conversion efficiency, the converter minimises power loss and operates with very low heat generation. It is rated to operate reliably up to a maximum working temperature of 80 degrees Celsius.

Multi-stage electrical protection

Integrated safeguard circuits provide overvoltage, overcurrent, overheat, and short-circuit protection. These mechanisms safeguard both the converter and your connected loads against unexpected power faults.

Waterproof and shockproof enclosure

The electronics are sealed in a robust waterproof and shockproof case designed for mobile and outdoor builds. The enclosure measures 58 x 40.5 x 22 mm and weighs 0.09 kg for straightforward mounting.

What is included

The package contains one 45W DC-DC converter module.
