keyestudio 9G MINI SG90 90 degrees Servo Motor Blue with PH2.54 Connector For Arduino Robot Car(1pcs)

The keyestudio 9G MINI SG90 is a compact 90-degree micro servo motor designed for precise angular movement in small-scale projects. Equipped with a PH2.54 connector, this lightweight motor is ideal for South African students, hobbyists, and makers building Arduino-based robot cars.

Precise ninety-degree angular control

The servo offers a controlled rotation range of approximately 90 degrees, mapped to a pulse-width range of 1000 to 2000 microseconds. It operates using a standard PWM signal cycle fixed at 20ms (50 Hz) to ensure reliable positioning.

Dual-voltage performance specifications

Operating between DC 4.8V and 6V, this micro servo delivers a stop torque of up to 1.3 kg/cm at 6V. It achieves a no-load speed of 0.12 seconds per 60 degrees at 4.8V, which improves to 0.1 seconds per 60 degrees when powered at 6V.

Standardised three-pin interface

The motor features three colour-coded connection lines consisting of brown for ground, red for 5V power, and orange for the PWM signal terminal. This standard layout simplifies wiring and integration with microcontrollers.

Compact and lightweight design

Weighing just 12g without its mounts, this mini servo measures 22.7mm by 12.12mm by 25.7mm. It includes a 250mm connection wire, making it easy to route within tight chassis spaces.

Included mounting accessories

Each servo comes with a variety of white motor mounts that connect directly to the output shaft. These horns can be used to drive mechanical linkages or serve as visual aids to track the motor's rotation.
