Description
The OKdo Radxa ROCK 5 Model B is an advanced single board computer powered by the octa-core Rockchip RK3588 SoC and 8GB of LPDDR4 RAM. Designed for demanding computing and multimedia tasks, it supports cutting-edge 8Kp60 display output and high-speed PCIe expansion. It is an ideal platform for makers, software developers, and educators working on advanced robotics, edge AI, and high-resolution video projects.
High-performance processing
Driven by an octa-core Arm DynamIQ processor combining quad Cortex-A76 cores and quad Cortex-A55 cores alongside an Arm Mali G610MC4 GPU, the board delivers robust computational power. It also includes 8GB of 64-bit LPDDR4 memory and hardware support for the RKNPU2 NPU software stack.
Advanced multimedia capabilities
The ROCK 5 Model B is equipped with dual HDMI output ports capable of driving displays up to 8Kp60 resolution, alongside a dedicated micro-HDMI input port that supports capture up to 4Kp60. Integrated 4-lane MIPI CSI and MIPI DSI interfaces provide direct connectivity for camera and display modules.
Extensive expansion and connectivity
Connectivity options include 2.5 Gigabit Ethernet with PoE support via an add-on HAT, USB 3.0 and USB 2.0 host ports, and high-speed M.2 M Key and E Key slots. A standard 40-pin GPIO header exposes multiple interfaces such as UART, SPI, I2C, PWM, ADC, and general-purpose I/O for external hardware integration.
Power and system controls
Power is supplied through a USB Type-C PD 2.0 interface or via dedicated 5V GPIO pins, requiring 24W to 36W depending on attached M.2 SSD storage. An integrated physical power button enables safe shutdowns to prevent data corruption, supported by an onboard real-time clock and fan connectors.
Downloads
Specifications
| SoC | Rockchip RK3588 |
| Processor | Arm DynamIQ (Quad Cortex – A76 @ 2.2/2.4GHz, Quad Cortex – A55 @ 1.8GHz) |
| GPU | Arm Mali G610MC4 GPU, supporting OpenGL® ES1.1, ES2.0, and ES3.2, OpenCL® 1.1, 1.2 and 2.2, Vulkan® 1.1 and 1.2, and embedded high-performance 2D image acceleration module |
| Memory | 8GB 64bit LPDDR4 RAM |
| Power Requirements | USB Type‑C™ PD Version 2.0 with 9V/2A, 12V/2A, 15V/2A and 20V/2A. 5V Power applied to the GPIO PIN 2 & 4. The recommended power source capacity is at least 24W without a M.2 SSD or 36W with a M.2 SSD. |
| HDMI | Dual HDMI ports supporting displays up to 8Kp60 resolution and 4Kp60 Micro-HDMI input port supporting up to 4Kp60 resolution |
| USB | 2x USB2 HOST ports 1x USB3 HOST port 1x USB3 OTG/HOST port |
| MIPI | 1x 4 lane DSI, 1x 4 lane CSI |
| Storage | Micro SD eMMC |
| UARTS | 2x UART |
| On/Off Power Button | YES |
| Software | Full implementation of the Arm architecture v8 instructions set Debian/Ubuntu Linux support Android 12 support RKNPU2 NPU software stack Hardware access/control library for Linux/Android |
| Temperature | Operation temperature: 0~50 ℃ Storage temperature: -20~80 ℃ |
| Device | Single Board Computer |
| Type | Model B | 8 GB |
| Display Output | Dual HDMI up to 8Kp60, 1x 4-lane MIPI DSI |
| Video Input | 1x Micro-HDMI up to 4Kp60, 1x 4-lane MIPI CSI |
| Ethernet | 1x 2.5 Gigabit Ethernet (PoE supported with add-on HAT) |
| PCIe Expansion | 1x M.2 M Key (PCIe 3.0 x4), 1x M.2 E Key (PCIe 2.1 x1, SATA, SDIO, UART) |
| USB Ports | 2x USB2 Type-A HOST, 1x USB3 Type-A HOST, 1x USB3 Type-A OTG/HOST, 1x USB Type-C |
| GPIO | 40-pin user GPIO (UART, SPI, I2C, PCM/I2S, SPDIF, PWM, ADC) |
| Operating Temperature | 0 to 50 deg C |
| Software Support | Debian/Ubuntu Linux, Android 12, RKNPU2 NPU stack |
