Description
The Kemo Electronic M048N is a compact flasher module designed to drive small glow lamps and light indicators. It supports standard flashing or alternating flashing across two outputs with an even duty cycle. Ideal for hobbyists, makers, and educational electronics projects needing simple visual signalling.
Dual output operation
The module features two independent outputs supporting up to 300 mA each. It can be configured for single flasher operation or alternating flasher effects.
Flashing frequency and duty cycle
It delivers a flashing frequency of 2 to 3 Hz, generating between 120 and 180 pulses per minute. The flashing rest relation provides an approximate 50:50 percent on-off balance.
Compact form factor
With dimensions of approximately 18 x 15 x 12 mm (excluding fixing straps), this module is easy to embed into tight enclosures and miniature model setups.
Specifications
| Operating voltage | 6...12 Vdc |
| Operating mode | flasher or alternating flasher |
| Output | 2 outputs each for max. 300mA |
| Flash sequence | 2~3 Hz (120~180 x per minute) |
| Flashing rest relation | approx. 50 : 50 % |
| Dimensions | approx. 18 x 15 x 12 mm (without fixing straps) |
