4-Phase 12V Geared Stepper Motor with 1/64 Reduction
We haven’t published a price for this one yet — ask and we’ll quote you, usually same day.
- Delivery nationwide via The Courier Guy — R150 flat, free over R2,000
- Free collection from our warehouse — address at checkout
- Secure checkout — PayFast card payment or EFT
- Questions? WhatsApp us on +1 555 318 8599
Description
This 12V 4-phase stepper motor provides precise angular positioning thanks to its built-in 1/64 gear reduction ratio. It interfaces easily with Arduino and other microcontrollers using standard driver boards like the ULN2003, making it an excellent component for hobbyists, students, and makers building automated systems.
Precise geared movement
With a stride angle of 5.625 x 1/64, this motor offers reliable, fine-step motion for precision control projects. Because of the internal gearing, the shaft cannot be rotated by hand and requires an electronic driver to operate.
Easy microcontroller integration
The 5-wire, 4-phase configuration is designed for direct connection to standard ULN2003 driver boards. Once connected to a driver shield, the motor can be controlled by an Arduino or other compatible MCU board.
Common applications
This motor is suitable for compact automation projects and is commonly used in air conditioner louvres, small cooling or heating fans, and positional control systems.
Downloads
Specifications
| Device | Stepper Motor |
| Type | 4 phase | 12V |
| Rated Voltage | 12VDC |
| Number of Poles | 4 |
| Wiring | 5 Line 4 phase |
| Speed Variation Ratio | 1/64 |
| Stride Angle | 5.625x1/64 |
| DC Resistance | 200 |
| Idle In-traction Frequency | >600Hz |
| Idle Out-traction Frequency | >1000Hz |
| In-traction Torque | >34.3mN.m(120Hz) |
| Self-positioning Torque | >34.3mN.m |
| Insulated Resistance | >10M (500V) |
| Insulated Electricity Power | 600VAC/1mA/1s |
| Dimensions | 31*27*19mm |
| Net Weight | 35g |
